LED Down Light
Model:SDL-4 9W/12WInquiry Now
Description:
Product Attributes :
◆Surface light source,luminous efficiency improved >50%
◆AL1070-99.7%Aluminum,thermal conductivity 220W/m.k
◆Using Epistar chip SMD2835 LED
◆High PF constant current driver,built-in/external
◆FRPVC cover,will never fade
◆6 different size can choose
※ Lamp parameter 规格参数
| Power 功率 | 9W | 12W |
| Input Voltage 输入电压 | 90-265VAC | |
| Frequency Range 频率范围 | 47～63Hz | |
| Power Factor(Typ. 功率因数 | PF>0.95/220VAC | |
| LED Brand LED品牌 | Epistar | |
| LED Quantity LED数量 | 45PCS | 60PCS |
| System Consumption 系统功耗 | 9±1W | 12±1W |
| LED Luminous Efficiency LED发光效率 | 70-80 Lm /W | |
| IP Rating 防护等级 | IP44 | |
| Junction Temperature LED结温 | ≤80℃ | |
| Color Temperature 色温 | 3000K/4500K/5000K/5700K/6500K | |
| Color Rendering Index 显色指数 | Ra＞80 | |
| Light Distribution 配光曲线 | Symmetric/round spot 对称式/圆形光斑 | |
| Life Span 光源寿命 | ≥50,000Hrs(Note3) | |
| The color of the lamp shell 灯具颜色 | white/ silver 白色、银色 | |
| Certification 认证 | CE ROHS | |
SDL-4 9W
※Size 尺寸
unit:mm
※Application 适用场所
High quality aviation aluminum radiator , high thermal conductivity, fast heat dissipation.
Perfect solve the heat problem, ensure LED life time .
Using imported acrylic matting face mask. High Density Emitting light is more crystal clear, bright, good transparency, softer light, highlighting the distinctive taste and style.
